Tube Line Up:
6A8M...1st. Detector/Oscillator
6K7M...I.F. Amplifier
6H6...2nd. Detector / AVC
6F5...1st Audio
6F6...Audio Output
5W4...Full Wave Rectifier
6G5...Tuning Indicator

Dementions:
Hight...22.5 inches
Wedth...15.5 inches
Depth...8.5 inches

Frequency Range:
BC Band...540 Khz - 1625 Khz
MW Band...1625 Khz - 5.7 Mhz
SW Band...5.7 Mhz - 18.0 Mhz
I.F. Frequency...460 Khz

Power Source:
AC...105 - 125 Volts

  The schematic for this radio can be found at the Nostalgia Air web site by clicking on the link below.

Schematic & Information
