Kadette 120
1937
International Radio
Corporation,
405 4th Street,
Ann Arbor, Michigan, USA
|
|
|
| | |
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
Tube Line
Up:
6K7G...R.F. Amplifier
6A8G...1st. Detector /
Oscillator
6K7G...I.F. Amplifier
6H6G...2nd. Detector /
AVC
6F5G...Audio Driver
6F6G...Audio
Output
5Y3...Rectifier |
|
|
| |
|
|
|
|
|
Frequency
Ranges:
BC Band (Yellow Dots)...540 kHz - 2000 kHz
P Band
(White Dots)...2.0 MHz - 7 MHz
SW Band (Red Dots)...7 MHz -
22 MHz
I.F.
Frequency...448 kHz |
|
|
| |
|
|
|
|
|
|
|
Power
Source:
AC...110 Volts |
|
|
| | |
|
|
|
|
|
Measurements:
Height...21 inches
Width...13
inches
Depth...10.5 inches |
|
|
| |
|
|
|
|
|
|
|
|
|
The schematic for this radio can be found at the Nostalgia
Air web site by clicking on the links below. |
|
|
| |
|
|
|
|
|
|
|
|
|
|
