Fada 790
1949
Fada Radio and Electric Company
Inc.
Belleville, New Jersey, USA
|
|
|
| | |
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
Tube Line
Up:
12AT7...F.M. R.F. and Mixer
6BE6...F.M. Oscillator / A.M.
Mixer and Oscillator
6BA6...AM/FM 1st. I.F.
Amplifier
6BA6...FM Driver
6AT6...AM Detector /
AVC / Preamplifier
6AL5...FM Detector / AVC
25L6...Audio
Output
25Z6...Rectifier
Ballast |
|
|
| |
|
|
|
|
|
Frequency
Ranges:
AM Band...540 kHz - 1800 kHz
FM Band...88 MHz - 108
MHz
AM I.F. Frequency...465 kHz
FM I.F. Frequency...10.7
MHz |
|
|
| |
|
|
|
|
|
|
|
Measurements:
Height...8.5 inches
Width...14
inches
Depth...7 inches |
|
|
| |
|
|
|
|
|
|
|
Power
Source:
AC / DC...105-125 Volts |
|
|
| | |
|
|
|
|
|
|
The schematic for this radio can be found at the Nostalgia
Air web site by clicking on the links below. |
|
|
| |
|
|
|
|
|
|
|
|
|
|
|
|
|
Schematic and
information |
|
|
| |
|
|
|
|
|
|
|
|
 |
|
|
|
|
|
 |
|
|
|
|
|
 |
|
|
|
|
|
|
|
|
